Model 5601MSC
Model 5601MSC Master SPG/Master Clock System
Page - 112 Revision 2.2 MASTER CLOCK
4.4.3.3. Selecting the Image Format of the SDI Video Test Generator
OUTPUT
The Image Format menu item is located within the Format sub-menu
and controls the video standard that is output from the SDI test
generator. The image format selections will depend on what the current
setting of the Interface menu item
is. Move the selection cursor to a
format and press the HELP button to obtain more information.
SDI TG 1
Format
Image Format
525i
625i
1920x1080i/59
1920x1080p/23
1920x1080p/29
1920x1080p/23sF
1920x1080p/29sF
2048x1080p/23
2048x1080p/23sF
1280x720p/59
1920x1080i/50
1920x1080p/25sF
1280x720p/50
1920x1080i/60
1920x1080p/24
1920x1080p/30
1920x1080p/24sF
1920x1080p/30sF
2048x1080p/24
2048x1080p/24sF
1280x720p/60
4.4.3.4. Selecting Sampling Structure of the SDI Video Test Generator
OUTPUT
The Sample Struct menu item is located within the Format sub-menu
and controls the video sample structure of the Dual-Link or 3G Level B
video output. This menu item will be forced to 422/10 YCbCr for Single
Link HD and Standard Def
interfaces. Move the selection cursor to a
format and press the HELP button to obtain more information.
SDI TG 1
Format
Sample Struct
422/10 YCbCr
444(4)/10 YCbCr
444(4)/10 RGB
444/12 YCbCr
444/12 RGB
422/12 YCbCr
