4.4.4.4. Configuring the On-Screen Message of the Analog Video Test Generator
It is possible to overlay a user-defined text message onto the output of the analog video test
generators. There are six menu items used to control the message displayed and are described below.
4.4.4.4.1. Enabling the On-Screen Message for the Analog Video Test Generator
OUTPUT
This menu item is used to enable the on-screen message for the ATG
and to select how many lines will be overlaid onto the output video.
When set to Message off, the text message will not be visible.
When set to Message 1 line, the first line of text will be overlaid onto the
picture of the ATG output.
When set to Message 2 lines, there will be two lines of text overlaid onto
the picture of the ATG output.
ATG 1
Message Ctl
Message off
Message 1 line
Message 2 lines
4.4.4.4.2. Setting the On-Screen Message Position for the Analog Video Test Generator
OUTPUT
There are two menu items used to control the position of the test
message on the ATG video output. When either menu item is selected,
the right LCD display will show a message position screen where the
active adjustment will be highlighted and the other adjustment will be in
dark text.
The H position menu item is used to control the horizontal position of the
text message.
The V position
menu item is used to control the vertical position of the
text message.
ATG 1
H Position
V Position
Message position
Vert. hor.
2 1
4.4.4.4.3. Setting the Text for the On-Screen Message of the Analog Video Test Generator
OUTPUT
There are two lines of user-defined text that can be entered using the
Message 1 and Message 2 menu items. When entering text, use the 
and  buttons or turn the control knob to set each character. Press the
SELECT button to advance to the next character. Turn the control knob
all the way counter-clock wise to get to the space character. There is a
maximum of 16 characters. When finished press the SELECT button.
The Message 1 menu item allows entry of text for the first message line.
The Message 2 menu item allows entry of text for the second line.
ATG 1
Message 1
EVERTZ 5601MSC
Message 2
MASTER SYNC
4.4.4.4.4. Setting the Font Size for the On-Screen Message of the Analog Video Test Generator
OUTPUT
This menu item controls the size of the font that is used for the on-
screen message text.
Select Normal size for normal sized letters.
Select Large size for large text that is easier to view on small monitors.
ATG 1
Message font
Normal size
Large size
