4.4.7.2. Setting the Phase of the AES and DARS Outputs
OUTPUT
There are two menu items used for setting the phase of the AES and DARS
outputs. When either of the AES coarse or AES fine
menu items are
selected the right LCD panel will show a phasing screen. The active phase
control will be highlighted while the other control will be shown in dark text.
Rotate the control knob or press the  and  buttons to change the phase.
Depress the knob while turning to make adjustments in larger steps.
Caution
: These menu items are live controls. Any adjustments made will
immediately affect the AES and DARS outputs.
The AES coarse menu item adjusts the phase of the outputs in steps of
entire subframes. This control is only applicable when in the PAL/integer
lock mode.
The AES fine menu item adjusts the phase of the outputs in steps of half of
a bit period (about 163ns).
AES Audio
AES coarse
AES fine
AES/DARS/WC
Phasing
Coarse fine
0 0
4.4.7.3. Setting the Phase of the Wordclock Outputs
OUTPUT
The WC phase menu item is used to set the phase of the wordclock signal
that is output by the 5601MSC. This is a global phase control that affects
any output which is configured to wordclock mode. Rotate the control knob
or press the  and  buttons to change the phase. Depress the knob while
turning to make adjustments in larger steps.
Caution
: The wordclock phase adjustment is a live control. Any changes
made will immediately affect the wordclock output(s).
The WC phase menu item adjusts the phase of th
e wordclock output in
steps of half of a bit period (about 163ns).
AES Audio
WC phase
Wordclock
Phasing
0
