Model 5601MSC
Model 5601MSC Master SPG/Master Clock System
Page - 116 Revision 2.2 MASTER CLOCK
4.4.3.7.4. Selecting the Font Size of the On-Screen Message for the SDI TG
OUTPUT
This menu item controls the size of the font that is used for the on-
screen message text.
Select Normal size for normal sized letters.
Select Large size for large text that is easier to view on small monitors.
SDI TG 1
Message font
Normal size
Large size
4.4.3.7.5. Enabling On-Screen Burn in for the SDI TG
OUTPUT
This menu item controls whether the on screen timecode burn in window will
be placed at the bottom of the SDI TG output image. This burn in window is
useful for tagging each frame with a unique timecode ID. The timecode
numbers replace image data hence they are “burned-in” to the picture.
Note that enabling
the burn in window does not insert any VITC or ancillary
timecode packets into the video.
SDI TG 1
TC Burn in
Off
On
4.4.3.7.6. Enabling Dropframe Counting for SDI TG
OUTPUT
This menu item allows the user to control whether the dropframe counting
mode will be used for the burn in timecode.
This menu item is only applicable to 29.97Hz and 59.94Hz video standards.
SDI TG 1
Dropframe Ctl
Off
On
4.4.3.7.7. Selecting When the Burn in Time is Synchronized to the System Time
OUTPUT
This menu item allows the user to set the time of day when the SDI burn in
timecode clock will be synchronized to system time. This synchronization is
necessary once per day to maintain a long-term correlation between the SDI
burn in time and system time for 29.97 and 59.94 frame per second rates.
Also, when the time reference is set to GPS, the SDI burn in time will have
to be synchronized to the system time to correct for leap seconds.
Enter the hour and minute with the  and 
buttons or by turning the
control knob.
The burn in clock can be synchronized to system time immediately using the
Jam Output menu item (see section 4.4.2.2.6).
All LTC, VITC and burn in timecode outputs can be synchronized to system
time in one shot using the Jam all VitcLtc menu item (see section 4.4.2.2.7).
SDI TG 1
Set Jam Time
0:00
4.4.3.7.8. Synchronizing the Burn In Time to System Time Immediately
OUTPUT
This menu item allows the user to synchronize the SDI burn in timecode
clock
to system time immediately. This synchronization will also happen
SDI TG 1
