Model 5601MSC
Model 5601MSC Master SPG/Master Clock System
MASTER CLOCK Revision 2.2 Page - 117
once per day at the time specified using the Set Jam Time menu item (see
section 4.4.2.2.5).
Caution: This menu item is a live control.
To synchronize the SDI burn in timecode to system time immediately, select
the Jam Output menu item and press the SELECT
button. The left LCD
screen will display TIME JAMMED in yellow for 2 seconds.
When the time reference is set to VITC or LTC and the frame rate of the time
reference is the same as the SDI output, the time will be jammed directly from
the time reference rather than from system time.
4.4.3.7.9. Synchronizing all the VITC, LTC, and Burn-In Clocks to System Time Immediately
This menu item allows the user to synchronize all LTC, VITC, and burn in
clocks to system time simultaneously.
Caution: This menu item is a live control.
To synchronize all the LTC, VITC and TG burn in clocks immediately, select
the Jam all VitcLtc menu item and press the SELECT button. The left LCD
panel will display ALL TIMES JAMMED in yellow for 2 seconds.
4.4.3.7.10. Setting the SDI Burn in Frame Offset
This menu item allows the user to set an offset between the system time
and the SDI burn in time. This feature is commonly used to compensate for
video path delays common within a television facility. The offset value will
be added along with the time zone offset (see section 4.4.2.2.9
Daylight Saving Time correction (see section 4.4.2.2.10) to obtain the final
VITC time. To advance the SDI burn in time earlier than the system time,
set the offset to a negative (-) value.
4.4.3.7.11. Selecting the SDI Burn In Time Zone Offset
This menu item allows the user to set a time zone offset between the
system time and the SDI burn in time. The time zone offset value is set in
30-
minute increments. The system time should be running at UTC. This
time zone offset will be added to the system time along with the Daylight
Saving Time correction (see section
4.4.2.2.10) and the SDI burn in time
frame offset (see section 4.4.2.2.8) to obtain the final SDI burn in time.
Use the and
buttons or turn the control knob to move the cursor to
select the desired time zone offset. Press the SELECT button to choose the
indicated value. It will then become highlighted to show it is the active value.
to
4.4.3.7.12. Enabling Daylight Saving Time for the SDI Burn In Time
This menu item allows the user to control whether Daylight Saving Time
