OVERVIEW
Audio Reference for the router (see section 3.6.4). Table 1-2 shows the model numbers of the
SoftSwitch equipped routers and the capabilities of each.
Audio
Model Video Configuration
Breakout
Panels
X1201S+SS SDI 12 x 1 None 0
X1201S-AES+SS SDI 12 x 1 2 12 x 1 1
X1201S-AES4+SS SDI 12 x 1 4 12 x 1 2
X1202S+SS SDI 12 x 2 None 0
X1202S-AES+SS SDI 12 x 2 2 12 x 2 1
X1202S-AES4+SS SDI 12 x 2 4 12 x 2 2
X1201H+HSS HD 12 x 1 None 0
X1201H-AES+HSS HD 12 x 1 2 12 x 2 1
X1201H-AES4+HSS HD 12 x 1 4 12 x 2 2
X1202H+HSS HD 12 x 2 None 0
X1202H-AES+HSS HD 12 x 2 2 12 x 2 1**
X1202H-AES4+HSS HD 12 x 2 4 12 x 2 2
Table 1-2: SoftSwitch Router Models
The Embedded SoftSwitch (referred to as ESS versions throughout this manual) versions of the router
have all the features of the SS versions as well as the following additional features. The embedded audio
on the Video 1 buss uses Evertz patent pending SoftSwitch technology to eliminate audible pops when
switches are performed. For the Embedded SoftSwitch technology to function correctly, the AES
sources must be synchronous with the Video reference and the Audio Reference for the router must be
set to video (see section 3.6.4). If Embedded SoftSwitch functionality is not required (e.g. Dolby E in the
embedded stream) then the DARS reference can be used with the AES portions of the router. Table 1-3
shows the model numbers of the Embedded SoftSwitch equipped routers and the capabilities of each.
Audio
Model Video Configuration
Breakout
Panels
X1201S+ES SDI 12 x 1 None 0
X1201S-AES+ES SDI 12 x 1 2 12 x 1 1
X1201S-AES4+ES SDI 12 x 1 4 12 x 1 2
X1202S+ES SDI 12 x 2 None 0
X1202S-AES+ES SDI 12 x 2 2 12 x 2 1
X1202S-AES4+ES SDI 12 x 2 4 12 x 2 2
X1201H+HES HD 12 x 1 None 0
X1201H-AES+HES HD 12 x 1 2 12 x 2 1
X1201H-AES4+HES HD 12 x 1 4 12 x 2 2
X1202H+HES HD 12 x 2 None 0
X1202H-AES+HES HD 12 x 2 2 12 x 2 1**
X1202H-AES4+HES HD 12 x 2 4 12 x 2 2
Table 1-3: Embedded SoftSwitch Router Models
