X1200 Series Router Manual
Page 3-6
Revision 1.3.2
OPERATION
3.5. FRONT PANEL SETUP MENU – MAIN MENU
The Front panel Setup menu is arranged in a layered structure that groups similar configuration items
together. The following section gives a brief description of the first level of menus that appear when you
enter the menu. Selecting one of these items will take you to the next menu level. Sections 3.6 to 3.16
provide detailed descriptions of each of the sub menus. The tables in sections 3.6 to 3.16 are arranged in
an indented structure to indicate the path taken to reach the control. Menu items or parameters that are
underlined indicate the factory default values.
REFERENCE
This menu is used to set up the Genlock Reference.
TRANSITION
This menu is used to set up the Transition type for audio and video.
INPUT SETUP
This menu is used to assign which video and audio inputs are enabled and
which audio busses are assigned to follow each of the video busses.
INPUT LABEL
This menu is used to change the default labels for the video and audio inputs.
OUTPUT SETUP
This menu is only available on the X1202H HD Router. It is used to select
whether the video outputs will be reclocked on non-reclocked.
BYPASS
This menu is used to manually active the video and audio bypass relays.
GPI SETUP
This menu is used to configure the 14 General Purpose inputs.
GPO SETUP
This menu is used to configure the 4 General Purpose outputs.
REMOTE
CONTROL
This menu is used to configure the Serial Remote Control port.
PRESETS
This menu is used to save and recall user presets, and to restore the router to
its factory default condition.
FIRMWARE
This menu is used to view the current firmware version and to upload new
firmware into the router.
3.6. CONFIGURING THE ROUTER REFERENCES
The ROUTER menus are used to configure the reference timing for the router. The chart below shows the
items available in the REFERENCE menu. On most routers only the Reference video menu item is
available. The other menu items are used for configuring the SoftSwitch features of routers fitted with
the SoftSwitch option. Sections 3.8.1 and 3.8.3 give detailed information about each of the sub menus.
Video Reference
Configures the video reference type.
Output Timing
Adjusts the timing of the video output V1 in relation to the Video Reference input
on SoftSwitch equipped routers
Input Timing
Adjusts the line synchronizer timing of the video output V1 in relation to the
Video Reference input on SoftSwitch equipped routers
Audio Reference
Selects the Audio reference on SoftSwitch equipped routers.
