OPERATION
Turning off Audio inputs in the Input Setup menu will cause the audio switch to be ignored by any AFV
Breakaway switching.
3.2.3. Independent Audio Bus Switching
On the early versions of the X1202 router that can be configured as a quad 12 x 1 AES, the audio busses
can be switched independent of the video buss. If one wishes to have an audio bus independent of an
AFV group switch, then that bus needs to be released from its AFV assignment using the Input Setup
menu. This shall be described later in the manual. If audio 1B has been released from its AFV
assignment it will switch as an independent bus.
When one selects the 1B key it will light up and all other bus selection keys will extinguish. One of the
twelve input keys will light and the display will show the audio input label for the selection. Pressing
another input key will cause that input to be selected on that bus only.
In independent Audio Bus switching, switch selection will be disallowed if the input has been turned off in
the Input Setup menu. A message “Input turned off” will be temporally displayed.
3.3. FRONT PANEL SETUP MENU
REFERENCE
−
Video Reference
−
Output Timing
−
Input Timing
−
Audio Reference
TRANSITION
−
Switch Line
−
Video Line Sync
−
Audio SoftSwitch
−
EA SoftSwitch
INPUT SETUP
−
AES Mode
−
Audio Follow V1
−
Audio Follow V2
−
Video V1 and V2
−
Audio 1A inputs
−
Audio 1B inputs
−
Audio 2A inputs
−
Audio 2B inputs
−
No Video Action
−
Input Standard
INPUT LABEL
−
Label Video
−
Label Audio 1A
−
Label Audio 1B
−
Label Audio 2A
−
Label Audio 2B
OUTPUT SETUP
−
Setup V1 Output
−
Setup V2 Output
BYPASS
−
Bypass All A & V
GPI SETUP
−
Disable All GPI’s
−
Enable All GPI’s
−
GPI Encoding
−
GPI Type
−
Program GPI’s
GPO SETUP
−
Disable All GPO’s
−
Enable All GPO’s
−
GPO Encoding
−
GPO Type
−
Program GPO’s
REMOTE CTL
−
Baud Rate
−
Serial Format
−
Serial Address
−
Serial control
−
Protocols
PRESETS
−
Load Factory
−
Load Preset 1
−
Load Preset 2
−
Save Preset 1
−
Save Preset 2
FIRMWARE
−
Firmware Version
−
Firmware Update
EXIT
−
Save and Exit
−
Exit no Save
−
Return to Menu
Figure 3-2: Overview of the Setup Menu
