3.6.1. Setting up the Video Reference
The Video Reference menu is used to select the type of video reference being used for the router. The
Video reference is used to control the switching point in the video when cross points are changed.
REFERENCE
Video Reference
ref:ntsc/60
ref:ntsc/59.94
ref:pal/50
The standard definition X1200S series router can accept only NTSC or PAL
video references.
REFERENCE
Video Reference
ref:ntsc/60
ref:ntsc/59.94
ref:pal/50
ref:1080i/60
ref:1080i/59.94
ref:1080i/50
ref:1080p/30*
ref:1080p/29.97*
ref:1080p/25*
ref:1080p/24sF
ref:1080p/23.98sF
ref:720p/60
ref:720p/59.94
The high definition X1200H series router can accept NTSC or PAL, or Tri-
level sync HD video references.
In general, the reference video should be chosen to match the standard of
the video program material passing through the router. For HD program
video, a standard definition reference video can be used as long as it is at
the same frame rate.
e.g. HDSDI PGM Video Analog Genlock Video
1080i/59.94 NTSC/59.94
1080i/59.94
1080i/50 PAL/50
1080i/50
720p/59.94 NTSC/59.94
720p/59.94
* These Video Reference formats are not available on the SS and ESS
versions of the X1200H
3.6.2. Setting up the Video Output Timing
(SoftSwitch and Embedded SoftSwitch routers only)
REFERENCE
Output timing
Course phase = 1
This menu item is used to set the vertical phase of the V1 output on the
SoftSwitch and Embedded SoftSwitch versions of the routers. The
course phase has valid values from 1 to the number of lines per frame and
adjusts V1 output phase delayed with respect to reference video. The
timing of the V2 output is not adjustable.
When the course phase is adjusted the “course phase” label will blink, when
the incoming signal that was selected when entering the set up menu, is
within the line synchronizer range.
