evertz X1201S - Table 3-2: HEX GPI Encoding Functions; Table 3-3: HEX Input Selection (HEX and AVF HEX Encoding)

X1200 Series Router Manual
Page 3-18
Revision 1.3.2
OPERATION
GPI # Action Function
1
2
3
4
High or low Level
Four HEX encoded inputs select one of
the 12 input busses – see Table 3-3
5 Falling Edge Switch selected input to V1 Output
6 Falling Edge Switch selected input to V2 Output
7 Falling Edge Switch selected input to 1A Output
8 Falling Edge Switch selected input to 1B Output
9 Falling Edge Switch selected input to 2A Output
10 Falling Edge Switch selected input to 2B Output
11
High or low Level
(only applicable when
AES4 option installed)
High: GPI 7 to 10 control breakaway of
audio associated with V1 video buss
Low: GPI 7 to 10 control breakaway of
audio associated with V2 video buss
12 Set by GPI type menu Set by Program GPI Menu
13 Falling Edge Switch selected input to AFV1 Outputs
14 Falling Edge Switch selected input to AFV2 Outputs
Table 3-2: HEX GPI Encoding Functions
GPI 4 GPI 3 GPI 2 GPI 1 Input Select
Low Low Low Low Invalid selection
Low Low Low High 1
Low Low High Low 2
Low Low High High 3
Low High Low Low 4
Low High Low High 5
Low High High Low 6
Low High High High 7
High Low Low Low 8
High Low Low High 9
High Low High Low 10
High Low High High 11
High High Low Low 12
High High Low High Invalid selection
High High High Low Invalid selection
High High High High Invalid selection
Table 3-3: HEX Input Selection (HEX and AVF HEX Encoding)
3.12.3.3. AFV HEX GPI Encoding
AFV HEX GPI encoding is designed to permit separate audio follow video switch selection for both V1 and
V2 busses. Four inputs are encoded to select one of the 12 inputs for the AFV1 group. Four inputs are
encoded to select one of the 12 inputs for the AFV2 group. Two GPI inputs perform the switch to one of
the AFV groups. There are four GPI inputs available for user defined functions.
GPI # Action Function
1
2
High or low Level Four HEX encoded inputs select one of
the 12 input busses – see Table 3-3
