OPERATION
BYPASS menu. The relays will not activate until you exit the menu system with the Exit and Save menu
choice. Sections 3.11.1 to Error! Reference source not found. give detailed information about each of
the sub menus.
Bypass All A & V
This menu allows the user to manually activate all video and audio bypass
relays.
3.11.1. Manually Activating All the Bypass Relays
BYPASS
Bypass All A & V
off
on
Manually activates all the bypass relays when set to On. Releases the
bypass relays when set to Off.
3.12. CONFIGURING THE GENERAL PURPOSE INPUTS (GPI)
The X1200 series routers can be controlled remotely by using 14 general purpose (GPI) inputs. The
functions of these inputs can be programmed to suit the specific requirements of the user. The GPI
SETUP menus are used to configure the functions of the GPI inputs. The GPIs can be configured to act
independently of each other or in one of three Encoded modes. In addition a global GPI disable function
allows the user to override the programmed functions of GPIs. See section 2.5 for information about
connecting the GPI inputs. The chart below shows the items available in the GPI SETUP menu. Sections
3.12.1 to 3.12.5 give detailed information about each of the sub menus.
Disable all Gpi’s
This menu allows the user to manually override the programmed functions
of all GPI inputs and disable them.
Enable all Gpi’s
This menu allows the user to turn off the manual override of the GPI inputs
and return them to their programmed functions.
Gpi Encoding
This menu allows the user to choose one of 4 pre-defined encoding modes
for the GPI inputs.
Gpi Type
This menu allows the user to select whether the GPI input will be level or
edge triggered.
Program Gpi’s
This menu allows the user to program different functions for the GPI inputs
that are not previously assigned using one of the encoding modes.
3.12.1. How to Override (Temporarily Disable) the GPI Functions
GPI SETUP
Disable all Gpi’s
Pressing the SELECT key when this menu item is shown will override the
programmed functions of all the GPI inputs. The GPI inputs will not respond
when they are disabled.
3.12.2. How to turn off the GPI Override (Return the GPIs to their Programmed Functions)
GPI SETUP
Enable all Gpi’s
Pressing the SELECT key when this menu item is shown will restore the
programmed functions of all the GPI inputs. Individual GPIs can be still be
disabled using the Program Gpi’s menu item (see section 3.12.5).
