evertz X1201S - Table 3-6: HEX Encoded Output Tallies; Configuring the Remote Control Port Operation

X1200 Series Router Manual
Page 3-22
Revision 1.3.2
OPERATION
GPO 4 GPO 3 GPO 2 GPO 1 Output Select
Low Low Low Low Power Off
Low Low Low High 1
Low Low High Low 2
Low Low High High 3
Low High Low Low 4
Low High Low High 5
Low High High Low 6
Low High High High 7
High Low Low Low 8
High Low Low High 9
High Low High Low 10
High Low High High 11
High High Low Low 12
Table 3-6: HEX Encoded Output Tallies
3.13.4. Configuring Whether the GPO Outputs are Latched or Momentary
GPO SETUP
Gpo Type
Gpo 1 type
gpo type:latch
gpo type:1/2 sec
This menu configures whether the GPO outputs that are available for user
functions will be latched or momentary (0.5 seconds in duration) when the
GPO encoding is set to none.
Individual menus for each GPO output allow each output to be
independently configured. For simplicity only the Gpo 1 type menu will be
shown.
3.13.5. Programming the GPO Output Functions
GPO SETUP
Program Gpo’s
Program Gpo 1
disable gpo
power failure
output v1 fail.
output v2 fail.
ref. video fail.
any v i/p fail.
sel. v i/p fail.
sel. v1 i/p tally
sel. v2 i/p tally
The Program Gpo menu is used to program the functions of the GPO
outputs that are available for user functions. Individual menus for
each GPO output allow each output to be independently configured.
For Simplicity only the Program Gpo 1 menu will be shown.
Disable GPO will turn off the GPO output
The rest of the GPO functions will cause one of the outputs to activate
as a tally for various conditions as shown in the chart below.
When one of the sel. xx i/p modes is selected the button
corresponding to the selected input will blink. To select another input
press the corresponding button (the input button LED will turn On) and
confirm your selection by pressing the SELECT key (the input button
Led will blink).
3.14. CONFIGURING THE REMOTE CONTROL PORT OPERATION
The X1200 series routers can be externally controlled using the REMOTE CONTROL port, or can operate
as a controller to another slave router. The REMOTE CTL menu is used to configure the parameters and
protocol for the Remote Control Port. The chart below shows the items available in the GPI SETUP menu.
