Wiring Diagram

Rivo™ I Controller EN

109

Evoqua Water Technologies GmbH | W3T597263 Issue 01-0624

HMI

USB 1

ETH 1

Ethernet

HMI

Backboard

Danger!

Do not unplug or plug in

interface connectors

while they are in operation!

RJ45
