Operation
10
Rivo™ I Controller EN
73
Evoqua Water Technologies GmbH | W3T597263 Issue 01-0624
Inputs / Outputs
Relay outputs
Depending on the configuration of the Rivo™ Flex Mod measuring modules.
e.g. Relay 1
(depending on the configuration)
Module information:
Hardware address, Part number, Serial number, Software version, Product
name, Error Code, State, Relay-Out
Label
Input: individual
Inverse
Select: ON – OFF
Enabled
Select: ON – OFF
Digital inputs
DI 1
Module information:
Hardware address, Part number, Serial number, Software version, Product
name, Error Code, State
Label
Input: individual
Input signal direction
Select: Direct – Inverse
Debouncing
Input: max 1000 ms
Controller function
Input: No function – Stop – Max. Dosing – Constant – 2xYout –
Ignore external setpoint / dosing factor
Controller
Input: Flow
