Evoqua Rivo I - Page 76

10
Operation
EN Rivo™ I Controller
74
W3T597263 Issue 01-0624 | Evoqua Water Technologies GmbH
DI 2
Module information:
Hardware address, Part number, Serial number, Software version, Product
name, Error Code, State
Label
Input: individual
Input signal direction
Select: Direct – Inverse
Debouncing
Input: max 1000 ms
Controller function
Select: No function– Stop – Max. Dosing – Constant – 2xYout –
Ignore external setpoint / dosing factor
Controller
Select: Flow
Analog outputs
Depending on the configuration of the Rivo™ Flex Mod measuring modules.
e.g. mA output 1
(depending on the configuration)
Module information:
Hardware address, Part number, Serial number, Software version, Product
name, Error Code
Label
Input: individual
Range
Select: 0 - 20 – 4 - 20
Stop behaviour
Select: 0 mA – 4 mA – 10 mA – 12 mA – 20 mA – 22 mA –
Hold last value
Measurement
Select: No select – Dosing factor – Flow sehr lang
