KPM.X.Systemhandbuch_X3.0.EN.V1.9 | 05/2019 | Subjects to misprints and technical changes.
2 Hardware and installation
Please check carefully to make sure the Xesar product you selected is suitable for your application.
We have made the required data sheet available on our homepage: https://www.evva.com/uk-
en/products/electroniclockingsystemsaccesscontrolsystems/xesar/
Figure 1: System architecture (sample image)
2.1 Xesar access components
Xesar's versatility offers different components, such as different escutcheon, handle, cylinder
shapes (including hybrid and cam locks), wall readers and padlocks.
Figure 2: Xesar access components (sample image)
