2.3 Xesar access components signal events
Signal
number
Event
Visual
signal
Audible signal
Note
Signal 1
Unlocking attempt
with authorised me-
dium
⚫⚫⚫⚫⚫
mmmmm
General: If several
cards are in use, the
signal is only output af-
ter the last card is read
(yes, no or no EVVA
card)
Signal 2
End of release
⚫⚫⚫⚫⚫
ttttt
Signal 3
Rejected
medium
⚫⚫-⚫⚫-⚫⚫-⚫⚫
hh-hh-hh-hh
Signal 4
Unlocking attempt
with authorised me-
dium and activated Of-
fice Mode
⚫⚫⚫⚫--⚫⚫⚫⚫
tttt—hhhh
Signal 5
Start of Office Mode
⚫⚫⚫⚫--⚫⚫⚫⚫
tttt—hhhh
Signal 6
End of Office Mode
⚫⚫⚫⚫--⚫⚫⚫⚫
hhhh—tttt
Signal 7
Opening attempt with
authorised medium,
signal indicates
drained battery
⚫⚫--⚫⚫--⚫⚫--
⚫⚫
h----h----h----h----
Signal 8
Battery inserted or
component reboot
⚫⚫--⚫⚫--⚫⚫
tt—mm—hh
After having inserted
batteries, battery
charge status display
possible
Signal 9
Medium without EVVA
segmentation; me-
dium faulty, other sys-
tem
No signals
Signal 10
Hardware faulty
⚫---⚫---⚫---
⚫---⚫---⚫---
⚫---⚫---⚫---
⚫---⚫---⚫---
⚫---⚫---⚫---
⚫---⚫---⚫---
⚫---⚫---
mmm---mmm--
-mmm---mmm-
--mmm---
mmm---mmm--
-mmm---mmm-
--mmm---
Signal 11
Communication
process with PPD
(Xesar)
⚫-⚫-⚫-⚫-⚫-
⚫
Signal 12
Communication
successful
⚫⚫⚫⚫⚫
hhhhh
