KPM.X.Systemhandbuch_X3.0.EN.V1.9 | 05/2019 | Subjects to misprints and technical changes.
Language-neutral assembly manual
To support Xesar access component assembly EVVA provides language-neutral assembly which
can be found on the packaging of the corresponding product or on our homepage.
https://www.evva.com/uk-en/products/electroniclockingsystemsaccesscontrolsystems/xesar/
Product-specific assembly video clips
We have provided assembly video clips with demonstrations of complex assembly steps here:
http://video.evva.com/tutorials/xesar/exdrz1/exdrz1-1/ domainhttp://video.evva.com/tutori-
als/xesar/exdrz1/exdrz1-1/
Language-neutral drilling template
EVVA provides a single-use, cardboard drilling template without text to support the assembly
of versions requiring one or several drilled holes. They are printed on the corresponding product
packaging and are available in our homepage in the general download section:
https://www.evva.com/uk-en/products/electroniclockingsystemsaccesscontrolsystems/xesar/
The assembly manuals and the packaging feature QR codes which will take
you directly to the corresponding video sequence or assembly manual.
Installation using drilling template
Figure 17: Drilling template (sample image)
EVVA provides a high-quality, metal drilling template to facilitate preparing the door for an assem-
bly of any type of Xesar escutcheons and Xesar handles.
An adjustable stop safeguards that holes are correctly aligned and it enables adaptations of the
settings to match the requirements of any door situation. Hardened metal drilling sleeves guarantee
a long service life even after intense use.
