Battery replacement
We recommend having batteries replaced by trained, specialist personnel only.
Replace batteries in due time, as soon as the escutcheon indicates "Battery low", see section: In-
stalling Xesar access components
Please note that specialist personnel must install Xesar access components as per the notes and
information as well as the assembly manual enclosed with the product.
EVVA provides a host of different installation tools to make installing your Xesar system easier.
Visit our website.
Language-neutral assembly manual
To support Xesar access component assembly EVVA provides language-neutral assembly which
can be found on the packaging of the corresponding product or on our homepage.
https://www.evva.com/uk-en/products/electroniclockingsystemsaccesscontrolsystems/xesar/
Product-specific assembly video clips
We have provided assembly video clips with demonstrations of complex assembly steps here:
http://video.evva.com/tutorials/xesar/exdrz1/exdrz1-1/ domainhttp://video.evva.com/tutori-
als/xesar/exdrz1/exdrz1-1/
Language-neutral drilling template
EVVA provides a single-use, cardboard drilling template without text to support the assembly of
versions requiring one or several drilled holes. They are printed on the corresponding product
packaging and are available in our homepage in the general download section:
https://www.evva.com/uk-en/products/electroniclockingsystemsaccesscontrolsystems/xesar/
Installation using drilling template
Figure 17: Drilling template (sample image)
EVVA provides a high-quality, metal drilling template to facilitate preparing the door for an as-
sembly of any type of Xesar escutcheons and Xesar handles.
An adjustable stop safeguards that holes are correctly aligned and it enables adaptations of the
settings to match the requirements of any door situation. Hardened metal drilling sleeves guaran-
tee a long service life even after intense use.
