Extron electronics DMP 128 User Manual

Command ASCII command
(host to device)
Response
(device to host)
Additional
description
Event Control
Read event buffer memory
EX3%
,
X3^
,
X3&
,
X3*
E
} X5$]
Write event buffer memory
EX3%
,
X3^
,
X3(
,
X3*
E
}
Evt
X3%
,
X3^
,
X3&
,
X3(
]
NOTE: Response to Write Event is padded with leading zeros for
X3%
and
X3&
.
Read string from event
buffer
EX3%
,
X3^
,
X3&
,
X4$
FE
}
{string}
]
Write string to event buffer
E
{string}*
X3%
,
X3^
,
X3&
FE
}
Evt
X3%
,
X3^
,
X3&
, {string}
]
NOTE: ‘F’ must be capitalized to read and write strings to event buffer memory.
Response to Write Event is padded with leading zeros for X3% and X3&.
Start events
E
1AE
}
Ego
]
Stop events
E
0AE
}
Est
]
Query # of running events
E
AE
}
#####
]
(5 digit number)
NOTES:
X3%
= Event number range 00-99
X3^
= Event buffer 0=receive 1=Unified
2=data 3=NVRAM
X3&
= Event buffer offset range 0 to Max buffer size
X3*
= Event data size (case sensitive) b=bit, B=Byte (8-bit), S=short (16-bit), L=long (32-bit)
X3(
= Event data to write
X4$
= number of Bytes to read range 1– 127
X5$
= Data element read ASCII digits representing numeric value of data elements read from buffer
(leading zeros suppressed)
DMP128 • SIS Programming and Control 139
