Extron electronics DMP 128 User Manual

Table 3: Mic/Line Inputs to Output Mix-points (
a
)
a
Mic/Line Inputs to Outputs
X6)
a
Mic/Line Inputs to Outputs
X6)
Mic/Line Input 1 to Output 1
20000
Mic/Line Input 2 to Output 1
20100
Mic/Line Input 1 to Output 2
20001
Mic/Line Input 2 to Output 2
20101
Mic/Line Input 1 to Output 3
20002
Mic/Line Input 2 to Output 3
20102
Mic/Line Input 1 to Output 4
20003
Mic/Line Input 2 to Output 4
20103
Mic/Line Input 1 to Output 5
20004
Mic/Line Input 2 to Output 5
20104
Mic/Line Input 1 to Output 6
20005
Mic/Line Input 2 to Output 6
20105
Mic/Line Input 1 to Output 7
20006
Mic/Line Input 2 to Output 7
20106
Mic/Line Input 1 to Output 8
20007
Mic/Line Input 2 to Output 8
20107
Mic/Line Input 3 to Output 1
20200
Mic/Line Input 4 to Output 1
20300
Mic/Line Input 3 to Output 2
20201
Mic/Line Input 4 to Output 2
20301
Mic/Line Input 3 to Output 3
20202
Mic/Line Input 4 to Output 3
20302
Mic/Line Input 3 to Output 4
20203
Mic/Line Input 4 to Output 4
20303
Mic/Line Input 3 to Output 5
20204
Mic/Line Input 4 to Output 5
20304
Mic/Line Input 3 to Output 6
20205
Mic/Line Input 4 to Output 6
20305
Mic/Line Input 3 to Output 7
20206
Mic/Line Input 4 to Output 7
20306
Mic/Line Input 3 to Output 8
20207
Mic/Line Input 4 to Output 8
20307
Mic/Line Input 5 to Output 1
20400
Mic/Line Input 6 to Output 1
20500
Mic/Line Input 5 to Output 2
20401
Mic/Line Input 6 to Output 2
20501
Mic/Line Input 5 to Output 3
20402
Mic/Line Input 6 to Output 3
20502
Mic/Line Input 5 to Output 4
20403
Mic/Line Input 6 to Output 4
20503
Mic/Line Input 5 to Output 5
20404
Mic/Line Input 6 to Output 5
20504
Mic/Line Input 5 to Output 6
20405
Mic/Line Input 6 to Output 6
20505
Mic/Line Input 5 to Output 7
20406
Mic/Line Input 6 to Output 7
20506
Mic/Line Input 5 to Output 8
20407
Mic/Line Input 6 to Output 8
20507
Mic/Line Input 7 to Output 1
20600
Mic/Line Input 8 to Output 1
20700
Mic/Line Input 7 to Output 2
20601
Mic/Line Input 8 to Output 2
20701
Mic/Line Input 7 to Output 3
20602
Mic/Line Input 8 to Output 3
20702
Mic/Line Input 7 to Output 4
20603
Mic/Line Input 8 to Output 4
20703
Mic/Line Input 7 to Output 5
20604
Mic/Line Input 8 to Output 5
20704
Mic/Line Input 7 to Output 6
20605
Mic/Line Input 8 to Output 6
20705
Mic/Line Input 7 to Output 7
20606
Mic/Line Input 8 to Output 7
20706
Mic/Line Input 7 to Output 8
20607
Mic/Line Input 8 to Output 8
20707
Mic/Line Input 9 to Output 1
20800
Mic/Line Input 10 to Output 1
20900
Mic/Line Input 9 to Output 2
20801
Mic/Line Input 10 to Output 2
20901
Mic/Line Input 9 to Output 3
20802
Mic/Line Input 10 to Output 3
20902
Mic/Line Input 9 to Output 4
20803
Mic/Line Input 10 to Output 4
20903
Mic/Line Input 9 to Output 5
20804
Mic/Line Input 10 to Output 5
20904
Mic/Line Input 9 to Output 6
20805
Mic/Line Input 10 to Output 6
20905
Mic/Line Input 9 to Output 7
20806
Mic/Line Input 10 to Output 7
20906
Mic/Line Input 9 to Output 8
20807
Mic/Line Input 10 to Output 8
20907
DMP128 • Reference Information 176
