Mic/Line Inputs to Outputs
X6)
a
Mic/Line Inputs to Outputs
X6)
Mic/Line Input 11 to Output 1
21000
Mic/Line Input 12 to Output 1
21100
Mic/Line Input 11 to Output 2
21001
Mic/Line Input 12 to Output 2
21101
Mic/Line Input 11 to Output 3
21002
Mic/Line Input 12 to Output 3
21102
Mic/Line Input 11 to Output 4
21003
Mic/Line Input 12 to Output 4
21103
Mic/Line Input 11 to Output 5
21004
Mic/Line Input 12 to Output 5
21104
Mic/Line Input 11 to Output 6
21005
Mic/Line Input 12 to Output 6
21105
Mic/Line Input 11 to Output 7
21006
Mic/Line Input 12 to Output 7
21106
Mic/Line Input 11 to Output 8
21007
Mic/Line Input 12 to Output 8
21107
Telephone Rx to Output 1
21200
Telephone Rx to Output 2
21201
Telephone Rx to Output 3
21202
Telephone Rx to Output 4
21203
Telephone Rx to Output 5
21204
Telephone Rx to Output 6
21205
Telephone Rx to Output 7
21206
Telephone Rx to Output 8
21207
