Table 4: Virtual Returns to Output Mix-points (
b
)
b
Virtual Returns to Outputs
X6)
b
Virtual Returns to Outputs
X6)
Virtual Return A to Output 1
21300
Virtual Return B to Output 1
21400
Virtual Return A to Output 2
21301
Virtual Return B to Output 2
21401
Virtual Return A to Output 3
21302
Virtual Return B to Output 3
21402
Virtual Return A to Output 4
21303
Virtual Return B to Output 4
21403
Virtual Return A to Output 5
21304
Virtual Return B to Output 5
21404
Virtual Return A to Output 6
21305
Virtual Return B to Output 6
21405
Virtual Return A to Output 7
21306
Virtual Return B to Output 7
21406
Virtual Return A to Output 8
21307
Virtual Return B to Output 8
21407
Virtual Return C to Output 1
21500
Virtual Return D to Output 1
21600
Virtual Return C to Output 2
21501
Virtual Return D to Output 2
21601
Virtual Return C to Output 3
21502
Virtual Return D to Output 3
21602
Virtual Return C to Output 4
21503
Virtual Return D to Output 4
21603
Virtual Return C to Output 5
21504
Virtual Return D to Output 5
21604
Virtual Return C to Output 6
21505
Virtual Return D to Output 6
21605
Virtual Return C to Output 7
21506
Virtual Return D to Output 7
21606
Virtual Return C to Output 8
21507
Virtual Return D to Output 8
21607
Virtual Return E to Output 1
21700
Virtual Return F to Output 1
21800
Virtual Return E to Output 2
21701
Virtual Return F to Output 2
21801
Virtual Return E to Output 3
21702
Virtual Return F to Output 3
21802
Virtual Return E to Output 4
21703
Virtual Return F to Output 4
21803
Virtual Return E to Output 5
21704
Virtual Return F to Output 5
21804
Virtual Return E to Output 6
21705
Virtual Return F to Output 6
21805
Virtual Return E to Output 7
21706
Virtual Return F to Output 7
21806
Virtual Return E to Output 8
21707
Virtual Return F to Output 8
21807
Virtual Return G to Output 1
21900
Virtual Return H to Output 1
22000
Virtual Return G to Output 2
21901
Virtual Return H to Output 2
22001
Virtual Return G to Output 3
21902
Virtual Return H to Output 3
22002
Virtual Return G to Output 4
21903
Virtual Return H to Output 4
22003
Virtual Return G to Output 5
21904
Virtual Return H to Output 5
22004
Virtual Return G to Output 6
21905
Virtual Return H to Output 6
22005
Virtual Return G to Output 7
21906
Virtual Return H to Output 7
22006
Virtual Return G to Output 8
21907
Virtual Return H to Output 8
22007
