Extron electronics DMP 128 User Manual

Table 5: EXP Inputs to Output Mix-points (
c
)
c
EXP Returns to Outputs
X6)
c
EXP Returns to Outputs
X6)
EXP Input 1 to Output 1
22100
EXP Input 2 to Output 1
22200
EXP Input 1 to Output 2
22101
EXP Input 2 to Output 2
22201
EXP Input 1 to Output 3
22102
EXP Input 2 to Output 3
22202
EXP Input 1 to Output 4
22103
EXP Input 2 to Output 4
22203
EXP Input 1 to Output 5
22104
EXP Input 2 to Output 5
22204
EXP Input 1 to Output 6
22105
EXP Input 2 to Output 6
22205
EXP Input 1 to Output 7
22106
EXP Input 2 to Output 7
22206
EXP Input 1 to Output 8
22107
EXP Input 2 to Output 8
22207
EXP Input 3 to Output 1
22300
EXP Input 4 to Output 1
22400
EXP Input 3 to Output 2
22301
EXP Input 4 to Output 2
22401
EXP Input 3 to Output 3
22302
EXP Input 4 to Output 3
22402
EXP Input 3 to Output 4
22303
EXP Input 4 to Output 4
22403
EXP Input 3 to Output 5
22304
EXP Input 4 to Output 5
22404
EXP Input 3 to Output 6
22305
EXP Input 4 to Output 6
22405
EXP Input 3 to Output 7
22306
EXP Input 4 to Output 7
22406
EXP Input 3 to Output 8
22307
EXP Input 4 to Output 8
22407
EXP Input 5 to Output 1
22500
EXP Input 6 to Output 1
22600
EXP Input 5 to Output 2
22501
EXP Input 6 to Output 2
22601
EXP Input 5 to Output 3
22502
EXP Input 6 to Output 3
22602
EXP Input 5 to Output 4
22503
EXP Input 6 to Output 4
22603
EXP Input 5 to Output 5
22504
EXP Input 6 to Output 5
22604
EXP Input 5 to Output 6
22505
EXP Input 6 to Output 6
22605
EXP Input 5 to Output 7
22506
EXP Input 6 to Output 7
22606
EXP Input 5 to Output 8
22507
EXP Input 6 to Output 8
22607
EXP Input 7 to Output 1
22700
EXP Input 8 to Output 1
22800
EXP Input 7 to Output 2
22701
EXP Input 8 to Output 2
22801
EXP Input 7 to Output 3
22702
EXP Input 8 to Output 3
22802
EXP Input 7 to Output 4
22703
EXP Input 8 to Output 4
22803
EXP Input 7 to Output 5
22704
EXP Input 8 to Output 5
22804
EXP Input 7 to Output 6
22705
EXP Input 8 to Output 6
22805
EXP Input 7 to Output 7
22706
EXP Input 8 to Output 7
22806
EXP Input 7 to Output 8
22707
EXP Input 8 to Output 8
22807
EXP Input 9 to Output 1
22900
EXP Input 10 to Output 1
23000
EXP Input 9 to Output 2
22901
EXP Input 10 to Output 2
23001
EXP Input 9 to Output 3
22902
EXP Input 10 to Output 3
23002
EXP Input 9 to Output 4
22903
EXP Input 10 to Output 4
23003
EXP Input 9 to Output 5
22904
EXP Input 10 to Output 5
23004
EXP Input 9 to Output 6
22905
EXP Input 10 to Output 6
23005
EXP Input 9 to Output 7
22906
EXP Input 10 to Output 7
23006
EXP Input 9 to Output 8
22907
EXP Input 10 to Output 8
23007
DMP128 • Reference Information 179
