Extron electronics DMP 128 User Manual

a
Inputs to EXP Outputs
X6)
a
Inputs to EXP Outputs
X6)
Input 11 to EXP Output 1
21017
Input 12 to EXP Output 1
21117
Input 11 to EXP Output 2
21018
Input 12 to EXP Output 2
21118
Input 11 to EXP Output 3
21019
Input 12 to EXP Output 3
21119
Input 11 to EXP Output 4
21020
Input 12 to EXP Output 4
21120
Input 11 to EXP Output 5
21021
Input 12 to EXP Output 5
21121
Input 11 to EXP Output 6
21022
Input 12 to EXP Output 6
21122
Input 11 to EXP Output 7
21023
Input 12 to EXP Output 7
21123
Input 11 to EXP Output 8
21024
Input 12 to EXP Output 8
21124
Telephone Rx to EXP Output 1
21217
Telephone Rx to EXP Output 2
21218
Telephone Rx to EXP Output 3
21219
Telephone Rx to EXP Output 4
21220
Telephone Rx to EXP Output 5
21221
Telephone Rx to EXP Output 6
21222
Telephone Rx to EXP Output 7
21223
Telephone Rx to EXP Output 8
21224
DMP128 • Reference Information 197
