Table 10: Virtual Returns to EXP Outputs
b
Virtual Returns to EXP
Outputs
X6)
b
Virtual Returns to EXP
Outputs
X6)
Virtual Return A to EXP Output 1
21317
Virtual Return B to EXP Output 1
21417
Virtual Return A to EXP Output 2
21318
Virtual Return B to EXP Output 2
21418
Virtual Return A to EXP Output 3
21319
Virtual Return B to EXP Output 3
21419
Virtual Return A to EXP Output 4
21320
Virtual Return B to EXP Output 4
21420
Virtual Return A to EXP Output 5
21321
Virtual Return B to EXP Output 5
21421
Virtual Return A to EXP Output 6
21322
Virtual Return B to EXP Output 6
21422
Virtual Return A to EXP Output 7
21323
Virtual Return B to EXP Output 7
21423
Virtual Return A to EXP Output 8
21324
Virtual Return B to EXP Output 8
21424
Virtual Return C to EXP Output 1
21517
Virtual Return D to EXP Output 1
21617
Virtual Return C to EXP Output 2
21518
Virtual Return D to EXP Output 2
21618
Virtual Return C to EXP Output 3
21519
Virtual Return D to EXP Output 3
21619
Virtual Return C to EXP Output 4
21520
Virtual Return D to EXP Output 4
21620
Virtual Return C to EXP Output 5
21521
Virtual Return D to EXP Output 5
21621
Virtual Return C to EXP Output 6
21522
Virtual Return D to EXP Output 6
21622
Virtual Return C to EXP Output 7
21523
Virtual Return D to EXP Output 7
21623
Virtual Return C to EXP Output 8
21524
Virtual Return D to EXP Output 8
21624
Virtual Return E to EXP Output 1
21717
Virtual Return F to EXP Output 1
21817
Virtual Return E to EXP Output 2
21718
Virtual Return F to EXP Output 2
21818
Virtual Return E to EXP Output 3
21719
Virtual Return F to EXP Output 3
21819
Virtual Return E to EXP Output 4
21720
Virtual Return F to EXP Output 4
21820
Virtual Return E to EXP Output 5
21721
Virtual Return F to EXP Output 5
21821
Virtual Return E to EXP Output 6
21722
Virtual Return F to EXP Output 6
21822
Virtual Return E to EXP Output 7
21723
Virtual Return F to EXP Output 7
21823
Virtual Return E to EXP Output 8
21724
Virtual Return F to EXP Output 8
21824
Virtual Return G to EXP Output 1
21917
Virtual Return H to EXP Output 1
22017
Virtual Return G to EXP Output 2
21918
Virtual Return H to EXP Output 2
22018
Virtual Return G to EXP Output 3
21919
Virtual Return H to EXP Output 3
22019
Virtual Return G to EXP Output 4
21920
Virtual Return H to EXP Output 4
22020
Virtual Return G to EXP Output 5
21921
Virtual Return H to EXP Output 5
22021
Virtual Return G to EXP Output 6
21922
Virtual Return H to EXP Output 6
22022
Virtual Return G to EXP Output 7
21923
Virtual Return H to EXP Output 7
22023
Virtual Return G to EXP Output 8
21924
Virtual Return H to EXP Output 8
22024
DMP128 • Reference Information 198
