View
• Meter Bridge — Opens a Meters dialog box with
real-time meters that monitor signal levels at each input
and output.
Figure 15. Meter Bridge
NOTE: Meter Bridge is available in Live mode only while connected using the
LAN port.
• Re-enable All Dialogs — Re-enables all dialog boxes, the pop-ups that allow
changes to block parameters.
• Group Controls — Opens the Group Controls dialog box (see Group Masters on
page82).
• Network Audio Control Meters
(AT models only) — This menu allows the
user to see the AT meters for an attached Dante
device.
To view the meters:
1. From the main DSP Configurator screen
toolbar, select View>AT Meters.
2. The Browse and Select Device dialog box
opens (see right).
3. Double-click the applicable device. The
meter display opens showing the Tx and Rx
channels. See Viewing AT Channels with
AT Meters on page125 for addtional information.
• Show All Channels — Enables channels previously hidden from the main menu
to be viewed. The selection provides an option to either show all hidden channels for
that selection, or by moving to the right, an individual channel can be selected while
leaving the others hidden.
DMP128 • Software Control 22
