In the detailed mode, SHAPE refers to the type of filter being used for that band, with a choice of
Notch, Bell Hi-Shelf or Lo-Shelf.
Range refers to the frequency range in which the band operates, with a choice of low frequency
(LF), low mid (LM), high mid (HM) or High Frequency (HF).
Mode 3. Bands 3 and 4 are shown in the detailed mode.
Mode 4. Hi and lo-pass filters are shown. Filter bands
In/Out at left, Hi/Lo selector at right
Hold down the ALT key for more functions.
EQ – ALT
EQ In/Out is toggled by an upper soft key. When EQ is in circuit, its graph line changes from grey
to heavy yellow, and the
EQ In button has a bright LED above it.
The four EQ modes are selected on the lower soft keys.
Path
Level is the main channel fader. Shown as OFF if below -99dB.
BLUE + Touch
Level knob (or Fader) set level to 0 dB
Pan values percentage left/right or front/back of center.
BLUE + Touch
Pan LR knob set Pan LR to center
Spread applies only to Link Groups. It is a measure of how wide the elements are panned into the
Surround field.
Divergence measures how tightly signal is panned to one position.
Rotate allows a signal path or Link Group to be rotated in the Surround field.
Hold down the
ALT key for more functions.
Path – ALT
Level ON / MUTE is the main channel MUTE switch.
Solo main channel solo
Solo Safe
prevents path being muted when another is soloed.
Insert IN
needs physical insert send and return paths defined.
MAIN
assigns or deassigns path from MAIN system bus
Armed
path must be a Track and have a patched input
Bus 1 - 4 extra mode where path can be assigned to Sub-buses 1 to 4 on the upper soft keys.
Bus 5 - 8 as above for buses 5 to 8
Dyn
There are three modes for Dynamics. All three stages of Dynamics may be active at the same
time (except for buses, which have no Expander / Gate stage). To switch between modes,
ALT +
lower soft keys.
Mode 1. Compressor
Mode 2. Expander / Gate. To toggle between Expander and Gate,
ALT + Dyn Type soft key
Mode 3. Limiter
