Fantic XE 125 - Maintenance; Trasmission Oil; Checking the Transmission Oil Level

4. Maintenance4. Maintenance
USE AND MAINTENANCE MANUAL CHAPTER 4
MAINTENANCE2-Strokes - Edition 00 / 2023
110
2
XX 125 / XE 125
1
XX 125 / XE 125
2
XX 250
1
XX 250
4.1 TRASMISSION OIL
Checking the transmission oil level
– Start the engine, warm it up for several minutes and wait
for five minutes;
– Place the machine on a level place and hold it up on upright
position by placing the suitable stand under the engine;
– Check the transmission oil level by removing control bolt
“1”. If oil leaks, the level is correct, while if it does not, add
oil from the appropriate loading opening “2” until the oil
comes out of the control hole;
Do not add additives or other substances and use
the products recommended in the “RECOMMENDED
PRODUCTS TABLE” section.
– Inspect the gasket (oil check bolt), replace if damaged;
– Tighten the oil check bolt.
Oil check bolt: 10 Nm (1.0 m•kg, 7.2 ft•lb)
