Fantic XE 125 - Right and Left Side Components (XE 125 Version)

13 Motore1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATION2-Strokes - Edition 01 / 2023
18
19 23 20
2122
24
13 14 15
18 1617
Right and left side components (XE 125 version)
Ref. Component
13 Kickstarter lever
14 Fuel tank
15 Radiator
16 Coolant drain bolt
17 Check bolt (Transmission oil level)
18 Rear brake pedal
19 Fuel cock
Ref. Component
20 Air filter
21 Drive chain
22 Shift pedal
23 Starter for cold start
24 Front fork
