Fantic XE 125 - Right and Left Side Components (XX 125 Version)

13 Motore1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATION2-Strokes - Edition 01 / 2023
16
14 18 15
1617
19
8 9 10
13 1112
Right and left side components (XX 125 version)
Ref. Component
8 Kickstarter lever
9 Fuel tank
10 Radiator
11 Coolant drain bolt
12 Check bolt (Transmission oil level)
13 Rear brake pedal
14 Fuel cock
Ref. Component
15 Air filter
16 Drive chain
17 Shift pedal
18 Starter knob
19 Front fork
