13 Motore1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATION2-Strokes - Edition 01 / 2023
54
1.15 MAINTENANCE INTERVALS
The following schedule is intended as a general guide to maintenance and lubrication. Bear in mind that such factors
as weather, terrain, geographical location, and individual usage will alter the required maintenance and lubrication
intervals. If you are a doubt as to what intervals to follow in maintaining and lubricating your machine, consult your
FANTIC dealer.
Periodic inspection is essential in making full use of the machine performance. The service life of the parts varies
substantially according to the environment in which the machine runs (e.g., rain, dirt, etc.). Therefore, earlier inspection
is required by reference to the list below.
The timely execution of the service and the relevant documentation is necessary for the correct use of the warranty.
Maintenance table (XX 125 version)
Item
After break-in Every race
(about 2.5
hours)
Every third
(about 7.5
hours)
Every fifth
(about 12.5
hours)
As required
Remarks
Piston
– Inspect and clean √√ Inspect crack.
– Replace √√
Inspect carbon deposits
and eliminate them.
Piston ring
– Inspect √√
Check the clearance
between the ends of the
piston ring.
– Replace √√
Piston pin, small end bearing
– Inspect √
– Replace √
Cylinder head
– Inspect and clean √√
Inspect carbon deposits
and eliminate them.
Check gasket.
– Retighten √√
– Replace √ Replace the gasket.
Cylinder
– Inspect and clean √√ Inspect score marks.
– Replace √ Inspect wear.
YPVS
– Inspect and clean √√
Inspect carbon deposits
and eliminate them.
Frizione
– Inspect and adjust √√
Check clutch housing,
driving plates, driven
plates and springs.
– Replace √
Transmission
– Replace oil √√
10W-40
(API SL / JASO MA MA2)
– Inspect √
– Replace bearing √
