2. Use of the vehicle
USE AND MAINTENANCE MANUAL CHAPTER 2
USE OF THE VEHICLE2-Strokes - Edition 01 / 2023
71
2
1
2
3
1
2
1
1
Sidestand (only for XE 125 version)
This sidestand “1” is used to support only the machine when
standing or transporting it.
Never apply additional force to the sidestand.
Hold up the sidestand before starting out.
Starter knob (choke)
When cold, the engine requires a richer air-fuel mixture for
starting. A separate starter circuit, which is controlled by the
starter knob “1”, supplies this mixture. Pull the starter knob
out to open the circuit for starting. When the engine has
warmed up, push it in to close the circuit.
Fuel cock (XE 125 version)
The fuel cock supplies fuel from the tank to carburetor and
also filters the fuel. The fuel cock has the three positions:
1. “OFF” : With the lever in this position, fuel will not flow.
Always return the lever to this position when the engine
is not running.
2. “ON” : With the lever in this position, fuel flows to the
carburetor. Normal riding is done with the lever in this
position.
3. “RES” : With the lever in this position fuel flows to the
carburetor from the reserve section of the fuel tank after
the main supply of the fuel has been depleted. Normal
riding is possible with the lever is in this position, but it is
recommended to add fuel as soon as possible.
Fuel cock (XX 125 / XX 250 versions)
The fuel cock supplies fuel from the tank to carburetor and
also filters the fuel. The fuel cock has the two positions:
1. “OFF” : With the lever in this position, fuel will not flow.
Always return the lever to this position when the engine
is not running.
2. “ON” : With the lever in this position, fuel flows to the
carburetor. Normal riding is done with the lever in this
position. Il rubinetto del carburante filtra il carburante
e lo eroga dal serbatoio al carburatore. Il rubinetto del
carburante ha due posizioni:
