Fantic XE 125 - Key to the Wiring Diagram Components (XX 250 Version)

13 Motore1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATION2-Strokes - Edition 01 / 2023
50
Key to the wiring diagram components (XX 250 version)
The following table lists all the components in the wiring diagram and their numbering.
Number Description of the electrical component
1
Engine stop switch
2
CDI unit
3
Ignition coil
4
Magnet flywheel
5
Diagnosis connector (OBD)
6
TPS sensor
7
Frame mass
8
Neutral sensor
9
Engine mapping selector
10
Carburettor solenoid valve
