1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATION2-Strokes - Edition 01 / 2023
47
1
Key to the wiring diagram components (XE 125 version)
The following table lists all the components in the wiring diagram and their numbering.
Number Description of the electrical component
1
OBD diagnosis connector
2
Engine control unit (CDI)
3
Ignition coil
4
Positive battery pole
5
Negative battery pole
6
Fuse 1 (7.5 A)
7
Fuse 2 (5 A)
8
Capacitor
9
Voltage regulator
10
Magnet flywheel
11
Pick-Up
12
Lights remote control switch
13
Speed sensor
14
Rear right turn signal
15
Tail light
16
Rear left turn signal
17
Front brake light switch
18
Rear brake light switch
19
Engine stop switch
20
Dashboard
21
Intermittent light
22
Left light stalk
23
Horn
24
Handlebar devices wiring harness interconnection
25
Front right turn signal
26
Front headlight
27
Front left turn signal
28
Engine stop switch
29
Engine mapping selector
30
TPS sensor
31
Power Jet
32
Light system resistance (4.7 k )
