Item Standard Limit
Rear disc brake:
Brake pedal position
Brake disc thickness
Brake disc offset
(as measured on the wheel)
Pump plunger inside diameter
Caliper plunger inside diameter
Brake fluid type
0.0 mm (0.00 in)
–
0.15 mm (0.0059 in)
11.0 mm (0.43 in)
25.40 mm (1.00 in)
DOT 4
–
3.5 mm (0.14 in)
1.0 mm (0.04 in)
–
–
–
Electrical (XX 125 and XE 125 versions)
Item Standard Limite
Ignition system:
Ignition system
Minimum advance (before TDC)
Pick-up coil resistance
Charge coil resistance 1
Charge coil resistance 2
CDI (Capacitive Discharge Ignition)
0.50 mm (0.02 in)
248.0–372.0 
720.0–1080.0 
44.0–66.0 
–
–
–
–
–
Ignition coil:
Primary winding resistance
Secondary winding resistance
0.24–0.36 
5.68–8.52 k
–
–
Pipa della candela:
Resistenza 5.00 k –
Charging system
CDI magnet –
Electrical (XX 250 version)
Item Standard Limite
Ignition system:
Ignition system
Minimum advance (before TDC)
Pick-up coil resistance
Charge coil resistance 1
Charge coil resistance 2
CDI (Capacitive Discharge Ignition)
0.18 mm (0.01 in)
248.0–372.0 
720.0–1080.0 
44.0–66.0 
–
–
–
–
–
Ignition coil:
Primary winding resistance
Secondary winding resistance
0.20–0.30 
9.52–14.28 k
–
–
Pipa della candela:
Resistenza 5.00 k –
Charging system
CDI magnet –
