13 Motore1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATION2-Strokes - Edition 01 / 2023
42
Item Standard Limit
Compression damping:
Adjusting system
Fast compression damping:
Unit for adjustment
Adjustment value from the start position
(Soft)
Adjustment value from the start position
(STD)
Adjustment value from the start position
(Hard)
Mechanical adjustable type
Turn
2
1-3/8
0
–
–
–
Slow compression damping:
Unit for adjustment
Adjustment value from the start position
(Soft)
Adjustment value from the start position
(STD):
XX 250
Adjustment value from the start position
(Hard)
Click
20
12
0
–
–
–
Swingarm:
Swingarm free play limit:
End
Side clearance
–
–
1.0 mm (0.04 in)
0.2–0.9 mm (0.01–0.04 in)
Wheel:
Front wheel type
Rear wheel type
Front rim size/material
Rear rim size/material:
XX 250
Rim runout limit:
Radial
Lateral
Deformation limit
Spoke wheel
Spoke wheel
21 × 1.60/Aluminium
19 × 2.15/Aluminium
–
–
–
–
–
–
–
2.0 mm (0.08 in)
2.0 mm (0.08 in)
0.50 mm (0.02 in)
Drive chain:
Measurement
Type
Number of links:
XX 250
Chain slack:
XX 250
Chain length (15 links)
520
Type without seal
114
48.0–58.0 mm (1.89–2.28 in)
–
–
–
–
–
242.9 mm (9.56 in)
Front disc brake:
Brake Disc Thickness
Brake disc offset
(as measured on the wheel)
Pump plunger inside diameter
Pump plunger inside diameter (left)
Brake fluid type
–
0.15 mm (0.0059 in)
9.52 mm (0.37 in)
25.4 mm, 25.4 mm (1 in, 1 in)
DOT 4
2.5 mm (0.10 in)
1.0 mm (0.04 in)
–
–
–
