4. Maintenance
USE AND MAINTENANCE MANUAL CHAPTER 4
MAINTENANCE2-Strokes - Edition 00 / 2023
131
4
1°
3°
5°
2°
4°
1 2
1
2
XX 125 / XE 125
1
1
2
XX 250
Remove bolts “1” and springs “2” of the clutch following a
cross pattern;
– Remove the pressure plate “1”;
(XX 125 / XE 125 versions)
– Remove the thrust bearing “1”, ball “2” and the push rod;
(XX 250 version)
– Remove the thrust bearing “1” and the push rod “2”;
