1. General information
USE AND MAINTENANCE MANUAL CHAPTER 1
GENERAL INFORMATION2-Strokes - Edition 01 / 2023
39
1
Item Standard Limit
Compression damping:
Adjusting system
Fast compression damping:
Unit for adjustment
Adjustment value from the start position
(Soft)
Adjustment value from the start position
(STD):
XX 125
XE 125
Adjustment value from the start position
(Hard)
Mechanical adjustable type
Turn
2
1-1/2
1-5/8
0
–
–
–
–
Slow compression damping:
Unit for adjustment
Adjustment value from the start position
(Soft)
Adjustment value from the start position
(STD):
XX 125
XE 125
Adjustment value from the start position
(Hard)
Click
20
12
14
0
–
–
–
–
Swingarm:
Swingarm free play limit:
End
Side clearance
–
–
1.0 mm (0.04 in)
0.2–0.9 mm (0.01–0.04 in)
Wheel:
Front wheel type
Rear wheel type
Front rim size/material
Rear rim size/material:
XX 125
XE 125
Rim runout limit:
Radial
Lateral
Deformation limit
Spoke wheel
Spoke wheel
21 × 1.60/Aluminium
19 × 1.85/Aluminium
18 × 2.15/Aluminium
–
–
–
–
–
–
–
–
2.0 mm (0.08 in)
2.0 mm (0.08 in)
0.50 mm (0.02 in)
Drive chain (XX 125):
Measurement
Type
Number of links
Chain slack
Chain length (15 links)
520
Type without seal
112
48.0–58.0 mm (1.89–2.28 in)
–
–
–
–
–
242.9 mm (9.56 in)
Drive chain (XE 125):
Measurement
Type
Number of links
Chain slack
Chain length (15 links)
520
Type with gasket
114
48.0–58.0 mm (1.89–2.28 in)
–
–
–
–
–
239.3 mm (9.42 in)
