Fayat DYNAPAC CT3000 - Page 57

Maintenance - Specifications
2018-02-20 4812325559EN 53
Specifications (cont.)
COMPACTING DATA
Cylinder diameter
4.97 ft (1,517 mm)
Cylinder width
3.28 ft (1,000 mm)
Compacting width (double pass)
14.4 ft (4,410 mm)
Pads per cylinder
60
Pads height
0.6 ft (185 mm)
Pads contact area
200 cm²
Pads distribution model
Chevron
PERFORMANCE DATA
Maximum theoretical speeds
(forward/reverse)
1st gear
2.30 mph (3.7 km/h)
2nd gear
5.34 mph (8.6 km/h)
3rd gear
9.07 mph (14.6 km/h)
4th gear
14,2 mph (20 km/h)
Torque
Torque for lubricated screws tighten with a torque wrench.
METRIC
THREAD
RESISTANCE CATEGORY
8.8
10.9
M4
1.8 lb.ft (2.5 N.m)
2.5 lb.ft (3.4 N.m)
M5
3.6 lb.ft (4.9 N.m)
5.2 lb.ft (7.0 N.m)
M6
6.2 lb.ft (8.4 N.m)
8.9 lb.ft (12 N.m)
M8
15.5 lb.ft (21 N.m)
20.7 lb.ft (28 N.m)
M10
29.5 lb.ft (40 N.m)
41.3 lb.ft (56 N.m)
M12
51.6 lb.ft (70 N.m)
72.3 lb.ft (98 N.m)
M16
124.7 lb.ft (169 N.m)
177 lb.ft (240 N.m)
M20
243.4 lb.ft (330 N.m)
346.7 lb.ft (470 N.m)
M24
420.4 lb.ft (570 N.m)
590.1 lb.ft (800 N.m)
M30
833.5 lb.ft (1,130 N.m)
1165.4 lb.ft (1580 N.m)
M36
1445.7 lb.ft (1,960 N.m)
2065.3 lb.ft (2,800 N.m)
Hydraulic system
OPENING PRESSURE
Transmission
16-21 bar
240 – 310 psi
Converter
1.7 – 4.8 bar
25 – 70 psi
Steering system
170 bar
2320 – 2465 psi
Blade system
140 bar
2000 psi
Brake system
40 bar
580 psi
