Maintenance – Specifications
54 4812325559EN 2018-02-20
Specifications (cont.)
Air conditioning (option)
The system described in this manual is the ACC (Automatic
Climate Control), that is, a system which maintains the set
temperature in the cab provided that all the windows and
doors are kept closed.
Coolant designation: HFC-R134:A
Coolant weight when full: 1,000 g (2.2 lb).
Engine
ENGINE
Make and model
Cummins QSB 6.7ℓ - Tier III / IV
Type
Turbo, Diesel, water coolant and air
cooling
Number of cylinders
6 in line, 4 periods
Power (SAE J1995)
194 kW (260 HP) @ 2,200 RPM (Tier III)
194 kW (260 HP) @ 2,200 RPM (Tier IV)
Rotation of idle speed
750 RPM
Blades
BLADES
Type
Leveling and tilting
Width
11.81 ft (3,600 mm)
Height
2,55 ft (780 mm)
