1. System overview CPI/CP system
1−10
Festo P.BE−CPEA−CL−EN en 0711a
The following list of CPI/CP modules shows in each case their
functions as well as the maximum possible number of inputs
or outputs on each CPI/CP module.
CPI/CP modules
Assigned I/Os
Type Type Module
supports
extended
functions
on CP masters
with extended
functions
on CP masters
without ex
tended functions
functions
E A E A
CPI/CP input
modules
CP−E08−M8−CL
CP−E08−M12−CL
CP−E16−KL−CL
CP−E16−M12−EL
CP−E16−M8−EL
CP−E32−M8−EL
CP−E16−M8
CP−E16N−M8
CP−E16−M8−Z
CP−E16−M12x2−5POL
CP−E16N−M12x2
CP−E16−KL−IP20−Z
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
No
No
8 E
8 E
16 E
16 E
16 E
32 E
16 E
16 E
16 E
16 E
16 E
16 E












16 E
16 E
16 E
16 E
16 E

1)
16 E
16 E
16 E
16 E
16 E
16 E






1)






CPI/CP output
modules
CP−A04−M12−CL
CP−A08−M12−EL−Z
CP−A08−M12−5POL
CP−A08N−M12
Yes
Yes
No
No




8 A
8 A
16 A
16 A




16 A
16 A
16 A
16 A
1) No function on CP master
Tab.1/3: Assigned I/Os of the CPI/CP modules
