1. System overview CPI/CP system
1−12
Festo P.BE−CPEA−CL−EN en 0711a
CPI/CP master type Number of
strings
Functionality Max. number
of inputs/out
puts per string
Max. number
of modules
per string
CPX with CP interface 4 CP 16 I + 16 O 2
4 CPI (advanced)
1)
32 I + 32 O 4
CP fieldbus node 4 CP 16 I + 16 O 2
CPV Direct 1 CP 16 I + 16 O 2
1 CPI (advanced)
1)
32 I + 32 O
1)
4
1)
CPV−SC−DP / CPA−SC−DP 1 CP 16 I + 16 O 2
1 CPI (advanced)
1)
32 I + 32 O
1)
4
1)
CPV−SC−DN / CPA−SC−DN 1 CP 16 I + 16 O 2
1 CPI (advanced)
1)
32 I + 32 O
1)
4
1)
CDVI−DN 1 CP 16 I + 16 O 2
1) Supporting the extended functions with CPV−DI02, CPV−CS02, CPV−DI02, CS02, DN3, CO3.
Tab.1/4: Over view, CPI/CP master
The compact CPI/CP I/O modules (type CP−...−CL and −EL)
described in this manual support the extended functions of
the CPI system. Combinations with other CPI/CP modules
are possible, but limit the number of CPI/CP modules per
string. The limitations described in section 1.1.2 apply.
Note
CPI I/O modules with extended functions, e.g. type
CP−...−CL, −EL can also be operated on CP masters without
extended functions (see Tab.1/3).
