5. Output module type CP−A08−M12−EL−Z
5−14
Festo P.BE−CPEA−CL−EN en 0711a
Status LEDs
Status display of output
Next to the actuator connections there is a yellow LED for
every output. This shows the status of the signal at the
relevant output.
LED status of
output
Status
LED lights up
Output supplies 1−signal
LED is out
Output supplies 0−signal
Tab.5/5: Status LEDs for status display of output
Status LEDs
Short circuit/overload
output
Next to the actuator connections there is a red LED for each
output. This shows a short circuit or overload at the output.
LED (red)
module
Operating status Error handling
LED is out
No short circuit/overload · None
LED lights up
Display module:
(1 per module, lights up when
an output LED lights up)
Short circuit/overload out
put (display module)
· Eliminate short circuit and delete the fault
1)
1)
Fault will not be deleted automatically.
Tab.5/6: Status LED short circuit/overload output (display module)
