Contents and general safety instructions
XI
Festo P.BE−CPX−CMAX−SYS−EN en 0908NH
Required software versions for the CPX nodes
Particular software versions for the CPX node are required for
operating the CMAX (versions as of August 2009):
CPX node
Required version
1)
Use Special features
2)
CPX−FEC From Revision 18 (R18) On request Max. 8 CMAX modules
CPX−FB6 (Interbus) From Revision 22 (R22) On request Max. 1 CMAX module
CPX−FB11 (DeviceNet) From Revision 20 (R20) Suitable Max. 8 CMAX modules
CPX−FB13 (PROFIBUS−DP) From Revision 23 (R23) Suitable Max. 8 CMAX modules
Acyclic services, DPV1
(then max.
7 CMAX modules)
CPX−FB14 (CANopen) From Revision 20 (R20) On request Max. 3 CMAX modules
CPX−FB23 (CC link) From Revision 19 (R19) On request Max. 8 CMAX modules
CPX−FB32 (Ethernet/IP) From Revision 14 (R14) On request Max. 8 CMAX modules
CPX−FB33 (PROFINET, M12) From Revision 7 (R7) On request Max. 8 CMAX modules
CPX−FB34 (PROFINET, RJ45) From Revision 7 (R7) On request Max. 8 CMAX modules
CPX−FB38 (EtherCAT) All On request Max. 8 CMAX modules
CPX−CEC In preparation On request Max. 8 CMAX modules
1)
Revisions version (Rev...) see name plate. Older revisions are not suitable for use with CMAX and
cannot lead to the intended behaviour.
2)
Depending on the CPX node functions used, the address range and therefore the maximum number
of modules can be further restricted, if necessary.
Tab.0/1: Over view CPX nodes
Please also observe the notes on the software version in the
documentation for the CPX node.
To commission the CMAX, you will require the Festo configur
ation tool with a CMAX plug−in. You can find this on the Festo
website at:
è www.festo.com ˛ Downloads ˛ Download Area:
Software,
drivers and firmware ˛ Enter search term: CMAX
