5. Diagnostics and error handling
5−40
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH
5.5.2 Information on the CMAX ([Module data] menu)
The module data of the CMAX is displayed in the
[Module data] menu.
System Over view _
CPX terminal
0: ... Module ...
1: ... Module ...
2: CMAX−C1−1 1 Serð
3: ... Module ...
_____________________________________________________
Diag ßà OK
1
2:CMAX−C1−1 _
Monitoring/Forcing (M)
Diagnostics (D)
Parameters (P)
Module data (MD)
_____________________________________________________
Back OK
2:CMAX−C1−1 :MD _
1 Servopneumatic axis
Type code: 176
Revision: 1
Serial No: 0x83000024
_____________________________________________________
Back
2
1
Module data" menu 2 Information
Fig.5/4: Displaying information with the CPX−MMI
Module data
Description
Type code Module code (CPX−specific, with the CMAX: 176)
Revision Firmware version (e.g. ’1’ for version 1.00)
Serial No Serial number of the CMAX
Tab.5/7: Module data on the CPX−MMI
