Festo CPX-CMAX-C1-1 Mounting, Installation And Diagnostics

5. Diagnostics and error handling
5−8
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH
5.2.4 Error numbers and warning numbers
Malfunction group 0  Configuration error
CPX error group 100 (CPX−MMI: [Configuration error])
No. Message Cause/description Error handling Type
1)
01 The target configuration
differs from the actual
configuration
2)
A component on the axis
string is not part of the
target configuration:
 Displacement encoder
or sensor interface
(type, length).
 Cylinder (type, length,
diameter).
 Valve (size).
· Check component and
replace, if necessary
· Accept actual con
figuration (download).
Error
level: F2
Reset: N
The displacement en
coder and the valve have
been exchanged and no
longer match the target
configuration or the
serial numbers have
changed.
· Check the axis con
figuration. Check to
make sure two axis
strings have not been
interchanged.
02 Unknown valve type Connected valve is not
supported.
· Exchange the valve or
· Update firmware.
Error
level: F2
Reset: N
03 Unknown cylinder type Connected cylinder or
the sensor interface is
not supported.
· Exchange the cylinder
or sensor interface or
· Update firmware.
Error
level: F2
Reset: N
04 Unknown type of dis
placement encoder or
sensor interface
Connected displacement
encoder or the sensor in
terface is not supported.
· Exchange the displace
ment encoder or sen
sor interface or
· Update firmware.
Error
level: F2
Reset: N
1)
For the error level and reset type, see section 5.2.3.
2)
To avoid tubing errors, the movement test is reset. CMAX has the status C03. The movement test
should be executed again afterwards.
