3. Electrical installation
3−9
Festo P.BE−CPX−CMAX−SYS−EN en 0908NH
3.2.2 CASM sensor interface
The CASM sensor interface has an incoming (S1) axis inter
face. See section 3.2.
A corresponding input (S2) for connecting the specific posi
tion measuring system is also available. See Tab.3/6.
Drive
Position measuring
system
Sensor interface Conne cti ng cable to the
displacement encoder
DGCI Permanently
integrated
 (no sensor interface
required)
KVI−CP−3−...
DNCI Integrated CASM−S−D3−R7 Permanently connected to DNCI.
DNC External,
MLO−POT−...−LWG
NEBC−P1W4−K−0
,
3−N−M12G5
DSMI Integrated
NEBC
−
P1W4
−
K
−
0
,
3
−
N
−
M12G5
DGP(L) External,
MLO−POT−...−TLF
CASM−S−D2−R3
NEBC A1W3 K 0 3 N M12G5
DNCM External, mounted on
delivery
NEBC−A1W3−K−0,3−N−M12G5
Tab.3/6: Over view of sensor interfaces and displacement encoder cables
