A. Technical appendix
A−3
Festo P.BE−CPX−CMAX−SYS−EN en 0908NH
A.1 CMAX technical data
CMAX, general
General technical data see CPX system manual P.BE−CPX−SYS−...
Product weight (with CPX−GE−EV−S) Approx. 240 g
Protection class as per EN 60 529, completely
installed, plug connector inserted or provided
with protective cap
IP 65
Protection against electric shock
(protection from direct and indirect contact as
per IEC/DIN EN 60204−1)
By means of PELV power circuit
(Protected Extra−Low Voltage)
Module code (CPX−specific) 176
Module identifier (in the handheld unit) CMAX−C1−1 Positioning module CMAX−C1−1
Tab.A/1: General technical data
CMAX power supply
Operating voltage /load voltage
The following special features apply:
 Load voltage range for valves (U
VAL
)
see CPX system description P.BE−CPX−SYS−...
20 ... 30 V
CMAX current consumption
 From operating power supply
Electronics/sensors (U
EL/SEN
)
of load voltage supply for valves (U
VAL
)
typically 200 mA at 24 V (see section 3.4.1),
max. 300 mA
typically 1 A ... 2 A at 24 V (see section 3.4.1),
max. 2.5 A
Galvanic isolation
 betweenthe operating voltage supply for the
electronics/sensors (U
EL/SEN
) and the load
voltage supply for the valves (U
VAL
)
No
Power failure bridging time 10 ms (for systems with the DGCI, a power
dropout > 1 ms causes an error E85)
Tab.A/2: Technical data for power supply
