A. Technical appendix
A−4
Festo P.BE−CPX−CMA X−SYS−EN en 0908NH
Positioning system with CMAX
Axis string
Number of axis strings / number of axes
Max. total length (all cables)
Type of axis interface
1 / 1
30 m
Socket M9, 5−pin
Operating modes
Record select mode
Number of positioning records
Record modes
Direct mode
Modes
Record select, direct mode, commissioning,
parametrising
64
Single record, configurable record switching
Point−to−point, continuous tracking
Control modes Position control, force control
Performance data
Repetition accuracy of position control
Repetition accuracy of force control
see Tab.A/4
2 % of the maximum force
LED displays P = Module status (error)
PL = Power load
Dx = Display/error, X axis
X = MC, X axis
Diagnostics Module−oriented diagnostics
Local 7−segment display
Undervoltage monitor
Valve and sensor monitoring
Storage of the last 100 diagnostic messages
Operating hour counter
Commissioning with FCT CMAX plug−in
by means of the master controller
Tab.A/3: Technical data of the positioning system
